Megohmmeter 10KV AC DC, High Voltage Megohmmeter Battery Voltage Tester Industrial Insulation Tester (US Plug)

Specification: Item Type: High Voltage Megohmmeter Material: ABS Battery: 1 x Polymer Battery 2500mAh (built in battery) DC Voltage Measurement Range: DC 0.0V-1000V, Resolution: ±1.5%rdg±3dgt, Accuracy: 0.1V AC Voltage Measurement Range: AC 0.0V-750V, Resolution: ±1.5%rdg±3dgt, Accuracy: 0.1V Function: Insulation Test, Voltage Test Rated Voltage: 250V, 500V, 1000V, 2500V, 5000V, 10KV Measurement Voltage (V): Rated Voltage x (1±10%) Insulation Range: 0.01MΩ-3000GΩ, Resolution: 0.01MΩ DC Voltage Range: 0-1000V, Resolution: 0.1V AC Voltage Range: 0-750V, Resolution: 0.1V Output Short Circuit Current: ≥5mA (10KV) Absorption Ratio Measurement: Yes Polarization Index Measurement: Yes Backlight: Controllable Gray White Screen Backlight, Suitable for Use in Dim Places Display Mode: 4 Digit Extra Large LCD Display, Gray White Screen Backlight USB Interface: With USB Interface, Software Monitoring, Data Storage Can be Uploaded to Computer, Save Print Test Line: High Voltage Rod Red 3 meters, High Voltage Test Line Black 1.5 meters, Green Line 1.5 meters Data Storage: 500 Sets, Blinking FULL Symbol Indicates Storage is Full Data Query Function: MR Symbol Displays Overflow Display Overload Overflow Function: OL Symbol Displays Alarm Function: Alarm Prompt When Measured Value Does Not Exceed Alarm Set Value Power Consumption: Standby: 30mA Maximum, Backlight On: 42mA Maximum, Measurement: 300mA Maximum How to Use: Follow the instruction manual to operate. PackageList: 1 x Tester 1 x Adapter 3 x Test Lines 2 x Cloth Tapes 1 x USB Cable 1 x CD 2 x Keys 1 x User Manual 1 x Aluminum Case

• Secure Measurement: This insulation tester automatically releases charges after measuring the insulation of the load, providing guard to ensure secure and measurement.
• Alarm Function: When the measured voltage value is greater than the alarm set value or the insulation value is less than the alarm crisis set value, the instrument flashes and emits beep alarm sound.
• USB Interface: This high voltage megohmmeter features a USB interface, supports software monitoring, and can upload stored data to a computer for saving and printing, efficient and practical.
• Multiple Gears Option: This digital insulation tester has multiple gear options for quick detection and key switching. It can select 250V, 500V, 1000V, 2.5KV, 5KV, 10KV for testing according to needs.
• Data Locking and Storage: After the measurement is completed, short press the MEM key to lock the current displayed data and automatically number and store it. Supports up to 500 sets of data storage.
